Here's the Jeep Patriot EV. Chrysler put a big EV logo on it. It’s fast and quiet. Give them all your taxpayer dollars. Heck, they even painted it green.
Jeep® Patriot EV
• Chrysler’s ENVI electric-vehicle technology meets industry’s most capable compact SUV
• 400-mile total driving range
• 40-mile all-electric range with zero fuel consumption and zero tailpipe emissions
Jeep® Patriot EV joins the growing portfolio of electric-drive vehicles being developed by Chrysler LLC.
As a Range-extended Electric Vehicle, the Jeep Patriot EV combines the electric-drive components of an Electric Vehicle with a small gasoline engine and integrated electric generator to produce additional energy to power the electric-drive system when needed. This provides the positive attributes of an Electric Vehicle with the driving range equivalent to today’s gasoline-powered vehicles.
“The Jeep Patriot EV expands our portfolio of ENVI electric-drive vehicles and is just one more example of what is possible through the technology Chrysler is developing,” said Lou Rhodes, President, – ENVI, and Vice President, Advance Vehicle Engineering, Chrysler LLC. “Moreover, the Patriot EV provides socially responsible, advanced electric technology in the industry’s most capable compact SUV.”
The Jeep Patriot EV features a refined and clean front appearance to match the refined and clean powertrain. The signature Jeep grille features vertical accents, and the front fascia is a separate component to help set the grille apart. The use of body-color paint, blended with matte black B- and C-pillars, visually creates a smooth and elongated profile.
The unique wheel design and size gives the Jeep Patriot EV a wide stance which combines with the paint treatment to produce a sporty form. The interior of the Jeep Patriot EV features all of the elements introduced in the refreshed 2009 Jeep Patriot.
The Jeep Patriot EV uses an electric-drive motor, advanced lithium-ion battery system and a small gasoline engine with an integrated electric generator to produce additional energy to power the electric-drive system when needed. Range-extended Electric Vehicles provide customers a no-compromise means of dramatically reducing their gasoline use and carbon footprint. The Jeep Patriot EV has a range of 400 miles, including 40 miles of zero fuel-consumption, zero-emissions, all-electric operation.
The Jeep Patriot EV features a new ENVI Green Pearl exterior with a prominent “EV” graphic adorning both sides – top-to-bottom – of the vehicle.
Jeep® Patriot EV – Vehicle Specifications
Vehicle Type Range-extended Electric Vehicle,
Weight and Dimensions
Length 173.6 inches / 4409 mm
Width 69.1 inches / 1755 mm
Height 65.7 inches / 1669mm
Wheelbase 103.7 inches / 2634 mm
Front overhang 34.8 inches / 883.9 mm
Rear overhang 35.1 inches / 892 mm
Track front / rear 59.8 inches / 1519 mm 59.8 inches / 1519 mm
Approach angle 27.5 degrees
Departure angle 31.4 degrees
Turn circle 35.6 feet / 10.85 m
Powertrain and Suspension
Layout Front-wheel drive
Motor Power: 150 kW (200 hp)
Battery Lithium-ion battery
Suspension Front - McPherson strut
Rear - Independent
Range extender SULEV gasoline engine and electric generator
Continuous electric power: 45 kW (60 hp)
Wheels and Tires
Tire size front P245 / 45R20 28.7 inches / 728 mm
Tire size rear P245 / 45R20 28.7 inches / 728 mm
Exterior ENVI Green Pearl
Interior Dark Slate Gray
Key Performance Attributes
0-60 mph (0-100 kph) approximately 8 seconds
Standing ¼-mile low-16 seconds
Top speed greater than 100 mph (approximately 161 kph)
All-electric range 40 miles (approximately 64 km)
Total driving range up to 400 miles (approximately 644 km)
