There are a few different systems used amongst teams. The notes above are based on the Jemba system which is the most common in the United States. All corners are broken into numbers 1-6 with a 1 being a hairpin and a 6 practically a straightaway. Some teams use a +/- modifier which is similar to sharps and flats in music or your report card in school. A 4+ is slightly faster than a 4 but not as fast as a 5-. Many teams get rid of most of the modifiers as it's too much to get out during a short period of time, especially on tight, fast stages that have tons of notes to be read.


This video is from WRC driver Ken Block and his Co-Driver Alex Gelsomino setting a record on Concord Pond in Maine using Jemba notes:

The Jemba system is produced by a computer which is run through the stage in the back seat of a car. The computer records all the G loadings and accelerometer data and after some manual inputs the computer prints out the books drivers get when you register for a rally. The nice thing is that nearly every feature is noted, which is why teams will cross out a bunch of irrelevant information to make the language simpler for the driver to follow at speed.


Plus you can only talk so fast and get out so many words. Unless you are a WRC team and then it sounds more like this:

You know what to cross out if you go to "recce" or reconnaissance, where you get to run the thru the stages at the legal speed limit and make adjustments to the notes. But even without Recce, an experienced co-driver can look at a set of notes and determine what is probably not necessary. There are also things in the notes that help the codriver maintain his place or allow you to regain your place if you get lost.


The driver doesn't always need to hear these notes, like a note for a bridge, unless it's narrow, after a high speed corner, slippery, or unusual — it's just a bridge. A whole section of 5's or 6's can be replaced with flat for 1000. Or something like that.

 When Horst Reinhardt Jr. and I were at Targa Newfoundland last month we replaced a whole subdivision stage with things like

"One block square right, two blocks left, right a tea green house, one block right, don't cut (there was a mean storm grate I didn't want to hit)"


…and so on.

We were able to rewrite the whole set of notes because the thing took place in a regular neighborhood and it was easier to call distances by blocks instead of using the "Tulips," which is a different style of notes. Oh, and our intercom had Bluetooth which I paired to my phone so we called Mike Spinelli and left all our random pacenotes on his voicemail for fun!


With Tulip notes, only the important corners are noted and there are little drawings showing the degree of the corner instead of full descriptions. And there was no recce. Here we are running a stage at Targa Newfoundland 2012 using the tulips:

The point is that the system is irrelevant as long as you are getting consistent information about what lies ahead in a timely manner that is easy to understand at high speed.


Other systems of notes are actually more about the pace of the road. If Jemba describes the road ahead, other systems describe how fast you should be going or what gear you should be in. So instead of telling you there is a certain degree corner ahead and letting you determine the speed, the notes will tell you to keep your foot on the gas and then tell you when you should start to slow down, sometimes by dictating the gear the transmission should be in for a particular corner or section.

Once the notes are accurate, then the timing of the note becomes critical. How far in advance do you want the note? How many corners ahead do you want read at once time? Here is Colin McRae discussing how he uses pacenotes:

No matter which version you use, pacenotes give the driver a view of the road ahead without being able to see it. They allow the driver to run flat out over a blind crest because he knows it's a straightway on the other side. They also provide guidance on driving style and where to place the car for the corner ahead. For example, the "Don't Cut" command which means don't cut across the apex of the turn, leave some room in the middle of the corner because there's going to be a boulder or a tree or something that protrudes ever so slightly into the road or the inside edge of the corner.


"Tidy" means don't hang it out. Keep the car clean in the center of the road thru the next section. It could be because of ruts on either side or little drainage walls like in the mountains at WRC Mexico.

Everyone focuses on the driver in rally but in many ways, the pace notes and co-driver are far more critical. Drivers make little mistakes all the time, but one little mistake by the person in the other seat and the driver launches the car off a cliff, or into the side of the mountain, as I did at Pikes Peak in 2011 when my co-driver turned two pages at once.


As a rally driver you have to trust your co-driver more than anything, even more than the look of the road ahead. If they tell you it's flat out, you better be flat out — but they also better be right!

If you don't listen to your co-driver, you'll be slow. It would be different if no team had notes and every crest has to be taken with caution. But if someone has notes and you don't, you don't stand a chance. Many say the difference between notes and no notes is a 20% increase in your time for the stage.

I think it depends on the terrain, but the numbers seem to support that percentage.

I've run stages with no notes because my co-driver is gagging from the party the night before combined with the heat and dust and everything else that makes a $500 RWD rally car miserable, and we were just under 20% slower than a similar stage run the day before with notes. And sometimes your co-driver screams and yells and swears like this Irish Tarmac video:

Even more to the point, NASA Rally Sport recently started letting drivers run without co-drivers at their stage rallies, and their times are roughly 20% off the other drivers. It's difficult to get a direct comparison as the cars are slightly different and the driver's experience varies, but there's no question that co-drivers and pacenotes are the key to fast rally times.

Hopefully this makes it easier to understand all those rally videos on YouTube. It's a huge language to explain, but these are the basics. If I missed something or you guys have a question, ask away in Kinja and I'll do my best to answer!
