Tesla's Removing Radar For Semi-Automated Driving On Models 3 And Y And I Don't Understand Why

Illustration for article titled Tesla's Removing Radar For Semi-Automated Driving On Models 3 And Y And I Don't Understand Why
Illustration: Tesla, JDT

If you’re paying any attention at all to the the world of Tesla or the ongoing quest for self-driving cars (not something I’m recommending for healthy, well-adjusted people, necessarily) you’ve probably been hearing a lot about something called Tesla Vision, which is not Tesla’s new Netflix competitor that deepfakes Elon Musk into every movie, but is rather Tesla’s new camera-only-based semi-automated system. Or, to maybe put it more bluntly, it’s a fancy name Tesla gave to the deletion of radar units in their top-selling cars.

Advertisement

Here’s how Tesla describes the new system themselves:

We are continuing the transition to Tesla Vision, our camera-based Autopilot system. Beginning with deliveries in May 2021, Model 3 and Model Y vehicles built for the North American market will no longer be equipped with radar. Instead, these will be the first Tesla vehicles to rely on camera vision and neural net processing to deliver Autopilot, Full-Self Driving and certain active safety features. Customers who ordered before May 2021 and are matched to a car with Tesla Vision will be notified of the change through their Tesla Accounts prior to delivery.

Previously, the radar systems in Tesla’s Autopilot driver-assist system worked in conjunction with the eight cameras used by the car to provide data about velocities and distances of objects. Radar is a very effective sensor for determining how far the car is from an object in front of it (as Tesla only uses forward-facing radar) and can work in the dark or in low visibility conditions that would impair a camera-based solution.

Radar can also bounce waves under cars in front of it to see objects that a camera can’t; you can see an example of this with a Tesla using its emergency braking feature (many cars have similar radar-based emergency braking systems) to stop the car because it spotted a car stopping in front of the car the Tesla was behind (you can hear the beeps when it detects the issue):

Interestingly, less than a year ago, it seems that Tesla was investigating the use of a more advanced radar system, as discovered by Tesla researcher/hacker GreentheOnly:

This isn’t the path for Model 3s and Ys, though, which will now be radar-less. The loss of the radar seems to have introduced some limitations, according to Tesla:

For a short period during this transition, cars with Tesla Vision may be delivered with some features temporarily limited or inactive, including:

  • Autosteer will be limited to a maximum speed of 75 mph and a longer minimum following distance. Smart Summon (if equipped) and Emergency Lane Departure Avoidance may be disabled at delivery.

In the weeks ahead, we’ll start restoring these features via a series of over-the-air software updates. All other available Autopilot and Full Self-Driving features will be active at delivery, depending on order configuration.

Advertisement

On previous radar-equipped cars, Autosteer would work up to 90 MPH, and the need for a longer minimum following distance is likely to make up for the lack of the quick and accurate radar-based distance sensor.

The part about Smart Summon and Emergency Lane Departure Avoidance (steers you back into your lane if it detects you’ve drifted out of it) maybe being disabled is confusing. Why can’t they say for sure if it’ll be disabled or not? Do those systems rely heavily on radar or don’t they?

Advertisement

The reasons why Tesla is eliminating radar from their highest-volume cars isn’t known just yet. While Tesla has long advocated for a more vision-based system (hence their rejection of Lidar) they haven’t been anti-radar, and they are keeping radar units on the more expensive Models S and X, which leads to speculation that there’s supply/cost issues that are motivating the removal.

Of course, among the Children of Elon, the elimination of a whole sensor system was cause for celebration and praise:

Advertisement

I’m just not convinced this is really a “courage” based decision, here. Without radar, all of the depth perception will have to be done algorithmically using input from two of the three forward-facing cameras, which have different lenses. It’s not ideal, as camera-based systems have to deal with all sorts of interference from light and weather and any number of things, where radar can give much more consistent distance readings.

Illustration for article titled Tesla's Removing Radar For Semi-Automated Driving On Models 3 And Y And I Don't Understand Why
Image: EET Asia (Other)
Advertisement

Plus, it’s not like those cameras are especially good; a teardown of the Model 3's camera systems described the 1280x960 resolution cameras as

Eight cameras in total designed into Model 3 are based on the same 1.2 Megapixel image sensors released by On Semiconductor in 2015. “They are low cost. They are neither new nor high resolution,” observed Fraux.

Advertisement

The same report described the radar setup like this:

The package also incorporates a forward-facing radar system with improved processing capabilities. It provides additional data about the surrounding environment on a redundant wavelength that can see through heavy rain, fog, dust and even beyond previous cars.

Advertisement

The key parts there are that the radar provides redundant distance data that can work in conditions cameras can’t; all of this seems pretty valuable to me. The radar unit used on the Model 3, a Continental ARS4-B, is used on a lot of other mid-priced cars like the Volkswagen Tiguan and Nissan Rogue, and isn’t a particularly expensive component, considering.

Other people, including well-known Tesla expert E.W. Niedermeyer, have noted the reality of the Model 3/Y cameras as well:

Advertisement

And, remember, Tesla’s cameras are not redundant; if the ones in that central pod of three get obscured by ice or rain or squished bugs or bird shit, or even blinded a sunrise/sunset, Autopilot disengages, and when it does, I sure as hell hope someone in that car is ready to take over.

There’s another justification for the decision I’ve seen that I’ve seen before in other contexts, and don’t really like it:

Advertisement

Here, our buddy Mike (who happens to be Facebook’s CTO) notes (correctly, I checked) that human drivers don’t need radar.

I’ve heard similar defenses of a vision-only approach, and claims that a Tesla can drive better than a human because we only have two little mobile cameras and a Tesla has eight.

Advertisement

This is true, but it’s an idiotic comparison, because how the visual data is processed from these cameras biological (eyes) and technological (cameras), couldn’t be more different.

Mammalian binocular vision with depth perception has been “in development” for millions of years, and the need to track prey while running in a wide variety of light and weather conditions adapts very well to the tasks of driving—there’s a hell of a lot of complex visual processing going on in a human brain when we drive, or catch a ball, thread a needle, or chase a dog escaped from their leash.

Advertisement
Illustration for article titled Tesla's Removing Radar For Semi-Automated Driving On Models 3 And Y And I Don't Understand Why
Screenshot: YouTube

We don’t need radar because we’ve evolved in a world where depth perception is important, and we’re quite good at judging it, and none of how we do it is remotely like the HydraNet architecture of Tesla’s FSD computer, even if we call those “neural” nets.

Advertisement

The approaches just aren’t the same. My dishwasher has spinning arms that spray water over dishes and I don’t, but I can wash dishes, too—albeit in a completely different way.

I’m sure it’s possible to do most of the Level 2, driver-always-ready-to-take-over semi-automation of Autopilot with just a camera-based system. Tesla is already shipping cars that will do it. I’m not convinced it’s better than having a redundant sensor system, and I’m not alone there.

Advertisement

Here’s Tesla hacker/researcher GreenTheOnly again:

Advertisement

Elon himself provided another explanation, one that I find especially unconvincing. This is from April, when the “pure vision” approach was being discussed:

Advertisement

The problems of sensor fusion are indeed difficult, but the result is a much richer view of the world, and more redundancy. Just because it’s hard shouldn’t mean that it should be abandoned, at least not for safety-critical things like cars. At one time, Elon was really into radar, too:

“Being radar it can see through rain, fog, snow, dust, and it recovers quite easily,” Musk said earlier in the call when describing radar’s advantages over the camera. “So even if there was something where you’re driving down the road and visibility was very low and there was a big multi-car pileup ahead of you, you can’t see it, but the radar worked, it would initiate braking before your car being added to the multi-car pileup.”

Advertisement

What happened to all that, Elon? It’s all still true, and it shows how radar can fill in some of the holes of a purely visual system.

I don’t think anyone outside of Tesla knows exactly why Tesla has decided to eliminate radar—cost issues, supply chain issues, complexity of integrating radar data with vision data, genuine belief in a vision-only system—but I don’t think they’ve yet managed to definitively prove that not having a redundant distance-measuring system that operates on different inputs than the primary system is a good idea.

Advertisement

If the goal is to be safer than a human driver, then I’m not yet convinced this makes sense. Maybe it’ll work out, for the current limited driver-assist level automation, but if Tesla’s still claiming they can get to full Level 5 autonomy by the end of this year, I don’t think the hardware in their current lineup can pull that off, and eliminating a whole sensor system like radar isn’t going to help.

Senior Editor, Jalopnik • Running: 1973 VW Beetle, 2006 Scion xB, 1990 Nissan Pao, 1991 Yugo GV Plus, 2020 Changli EV • Not-so-running: 1977 Dodge Tioga RV (also, buy my book!: https://rb.gy/udnqhh)
