Could You Drive The Gordon Murray T.50 By Only Using Its Big-Ass Fan?

Illustration for article titled Could You Drive The Gordon Murray T.50 By Only Using Its Big-Ass Fan?
Graphic: Jason Torchinsky/GMA

I think we’ve all been pretty dazzled by the new Gordon Murray Automotive T.50 hypercar—and I normally find that word kind of eye-rollish, but in this case I think it’s justified. It’s such a pure exercise in technology employed to make driving really exciting: small, featherweight, an advanced, naturally-aspirated V12, carbon body, and, maybe most excitingly, that big-ass fan on the back. Now, the fan is for complicated aerodynamic purposes, but there’s something I can’t help but wonder: could you drive the car with only the fan?

Advertisement

I know it’s kind of an idiotic question, but when you have a big fan exhaust on the back that’s blowing out air and looks like a jet engine, it’s really hard not to imagine it pushing that car along. And it’s not like the fan doesn’t generate any forward thrust—we know it generates about 33 pounds of thrust, because Gordon Murray told us so.

Advertisement

So, if it’s generating thrust, I think it should be able to move the car. The question is really how fast could it move it? I know 33 pounds of thrust isn’t much, but if I recall, thrust is cumulative—that’s why those NASA probes with the little ion engines that make as much thrust as a piece of paper exerts on a desk can eventually get those probes moving so fast.

Illustration for article titled Could You Drive The Gordon Murray T.50 By Only Using Its Big-Ass Fan?
Graphic: Jason Torchinsky/GMA

I realized I needed to do some actual math here, and I also know my limitations, of which I have so so many, including not being great at math. So, with that in mind, I reached out to Jalopnik’s semi-tamed physicist, Dr. Stephen Granade, to see if we could figure out —at least roughly—if the fan can actually move the car, and, if so, how fast could it move it?

Here’s what Stephen had to say:


I love that you looked at a car that’s the pinnacle of Gordon Murray’s career, that should hit 60 MPH in under three seconds, and said, “Okay, sure, but could you push it with its fan?”

Advertisement

That’s not a ridiculous question. A fan is just a propeller in a hoodie. And like an airplane’s propeller, the T.50’s fan produces thrust. When it spins, it accelerates air backwards, which pushes the fan, and the whole car, forward.

It’s complicated to figure out how much thrust a fan produces. The further out on a fan blade you go, the faster it moves through the air. It’s like how you get dizzier on the edge of a merry-go-round than in the middle. That changes how each part of the blade interacts with the air. While I can look at pictures of the T.50’s fan with its seven straight blades, without knowing the actual blade shape, I can’t calculate its thrust.

Lucky for us, GMA told us it can produce 33 pounds of thrust. Is that enough to make the car move? Probably so. If I put my ancient Honda Fit’s gear stick in neutral, I can make it roll on level ground by sticking my foot out of the door and pushing, and my car isn’t anywhere near a hypercar. It’s more of a hypocar.

But saying “probably so” and calling it a day isn’t any fun. You know what is fun? Math.

Thrust is a force, which equals mass times acceleration. Divide the thrust by the T.50’s mass and we’ll know how fast the fan can accelerate the car. The T.50’s extremely light, with a curb weight of under 2200 pounds (1000 kg), less than my Fit. If you’re fine with the fan pushing an unoccupied car, then it can accelerate the car at a blistering half a foot per second per second. That’s 0 to 60 in around 3 minutes.

But even small amounts of thrust add up over time. In space, NASA’s used ion thrusters that barely produce enough thrust to lift four pennies, but over a long period of time changed the spacecraft’s speed by nearly 25,000 MPH.

Great! Let’s get a fan-pushed T.50 up to ludicrous speeds! Unfortunately, by working in space, NASA avoids two things: friction and air resistance.

Friction may keep us from getting the car rolling in the first place. The fan’s thrust has to overcome the wheel bearing’s at-rest friction, and the tires’ deformation adds to that friction.

If we have to, we can get around that by giving the car a hard push ourselves, though mind the fan! The fan should then keep the car rolling forward. As it picks up speed, though, air resistance climbs. Roughly speaking, when you double a car’s speed, the aerodynamic drag force goes up by four. Even for a low-drag car like the T.50, at some point the air will push back as hard as the fan pushes forward.

Advertisement
Illustration for article titled Could You Drive The Gordon Murray T.50 By Only Using Its Big-Ass Fan?
Graphic: Advances in Science and Technology Research Journal Vol. 12 (2), 2018 (Fair Use)

A recent numerical analysis of the drag force on a very crude “sports car” CAD model indicates that we’ll reach that point around 48 miles per hour. But without knowing the T.50’s aerodynamic characteristics, I can’t tell you how right that number is.

Of course, there’s one way to find out for sure. Is there $3M in the Jalopnik budget for a T.50?

Advertisement

Okay, so, let’s recap:

Yes, the Gordon Murray T.50 could propel itself with only the thrust from its rear-facing fan, producing 33 pounds of thrust. With a curb weight under 2,200 pounds and factoring in some degree of rolling resistance, we’re looking at accelleration of six inches per second, every second, or a 0 to 60 time of about three minutes.

Advertisement

Except it likely couldn’t quite get to 60 MPH.

As far as top fan-only speed goes, if the aero of the car is roughly in the ballpark of that racing car model used in that Polish research paper (it’s probably not that far off) then we can expect a top speed of around 48 MPH before the drag on the car limits the acceleration. Let’s be generous and say that the T.50 probably has better aero, so we can maybe push that to 50 MPH.

Advertisement

Now, let’s put that in a fun graphic:

Illustration for article titled Could You Drive The Gordon Murray T.50 By Only Using Its Big-Ass Fan?
Graphic: Jason Torchinsky/GMA
Advertisement

So, there you go! One of the fastest cars you can buy (well, probably not you, or me, or anyone I actually know) becomes one of the slowest if you don’t let it actually drive its own wheels directly. Then again, if you add those no-drive-wheels criteria to almost any other car at all (with the possible exception of a the Helicron), then the T.50 once again proves to be faster than almost anything else.

Now, I want to be clear that we do not yet have official numbers for the T.50's coefficient of drag or frontal area; I’ve reached out to GMA and have yet to hear back, but I’m hoping now that this story is up perhaps they’ll understand the gravity of this and if they can get me the proper numbers, we’ll update the chart and data accordingly.
